Intel 6th/7th gen, Q170 Express chipset, mini ATX
| Form Factor | Mini ITX 6.7” x 6.7” (170mm x 170mm) |
|---|---|
| Processor | 6th & 7th Gen Intel® Core™ i7/i5/i3, Pentium and Celeron |
| Chipset | Intel® Q170 Express |
| BIOS | AMI® UEFI BIOS |
| Memory | 2 x SO-DIMM, 2133/2400 MHz sockets for up to 32GB maximum memory |
| USB 2.0 | 8 |
| USB 3.0 | 4 |
| SATA | 6 x SATA III + 1 x mSATA |
| COM | 5 x RS232 serial ports, 1 x RS232/422/485 serial port |
| VGA | 1 x VGA |
| HDMI | 1 x HDMI |
| DP | 1 x Display port |
| LVDS | Dual channel 18/24-bits, LVDS (Chrontel CH7511B eDP to LVDS) |
| Audio | Realtek ALC892 |
| Ethernet | Intel® i219LM + Intel® i211AT |
| Watchdog | Yes |
| Power | ATX combo connector |
| PS/2 Keyboard/Mouse | PS/2 Keyboard and PS/2 Mouse |
| Operating Temp | 0~60°C (32~140°F) |
| Non Operating Temp | -40~ 75°C |
| Operating Humidity | 0%~90% relative humidity, non-condensing |
| Compliance | FCC, CE, RoHS |
| Part Number | Q17IX |
