CorMed-M24™
Industrial touchscreen VESA mount 24” widescreen with LED backlight with wide range of connectivity and I/O options
Technical Specifications
| Form Factor | 606mm x 398mm x 65.6mm (23.85” x 15.66” x 2.58”) |
|---|---|
| CPU | Intel® 10th Gen. Core i7/i5/i3/Pentium/Celeron Processor (35W Max.) |
| Chipset | Intel® Q470E Chipset |
| Memory | Two (2) 260-pin SO-DIMM, Dual Channel DDR4 2933 / 2666 / 2400 MHz, up to 64GB |
| Storage | One (1) 2.5” SATA HDD drive bay, 1 x M.2 (M Key, 2280) w/PCIex4 & SATA3 for SSD |
| I/O | 4 x USB 3.2 Gen II, 1 x 4KV ISO USB 2.0 1 x 4KV ISO RS232, 1 x 4KV ISO RS232/RS422/RS485 2 x Gigabit LAN 1 x HDMI 1 x DP 2 x 3.5mm Audio Jack (Line-out, and Mic-in) 1 x DC Input 24V 1 x Reset button |
| Ethernet | 2GB Ethernet Ports |
| Video | Intel® integrated UHD Graphics |
| Audio | Intel® HD Audio |
| Display | 24” touch panel (10 fingers) / Full HD 1920 x 1080 |
| Power | Power Adaptor: 2M DC Extension Cable |
| Certification | AC input: 100 ~ 240V AC (Full Range); Output: 24V DC, 180 watts |
| Software | Microsoft Windows® 10 & 11 |
| Webcam | HD 2.0 Megapixel |
| Weight | 10.8 kg (w/o power adapter) |
| Mounting | VESA mounting |
| Part Number | N/A |
