W48AX
Intel 10th Gen., W480-E chipset, ATX
Technical Specifications
The W48AX is based on the Intel W480E chipset. This industrial motherboard supports DDR4 ECC or non-ECC, 2 USB 3.2 Gen 1, 1 USB 3.2 Gen 2, and 4 USB 2.0.
| Form Factor | ATX | 12” x 9.6” (305mm x 244mm) |
|---|---|---|
| Chipset/Processor | Chipset | Intel W480E |
| CPU | 10th Gen Intel® Comet Lake & Xeon | |
| Speed | N/A | |
| TDP | N/A | |
| Core/Threads | N/A | |
| BIOS | BIOS | AMI UEFI BIOS with CSM support |
| Expansion Slots | PCI-Express | 1/0 x PCIex16 (x8 with bifurcation) |
| 0/1 x PCIex8 (x8 with bifurcation) | ||
| 2 x PCIex4 | ||
| 3 x PCIex1 | ||
| Memory | DIMM | Dual Channel DDR4 (2933MHz), ECC or non-ECC U-DIMMS, up to 128GB |
| Graphics | VGA | 1 |
| LVDS | N/A | |
| DP | 2 | |
| Internal Connectors | USB | 2 x 3.2 Gen1 |
| 1 x 3.2 Gen2 (with power) | ||
| 4 x 2.0 | ||
| Audio | 1 x front audio | |
| SATA | 4 | |
| M.2 | 3 | |
| Serial Ports | 4 | |
| GPIO | 1 | |
| Power | 1 x 24pin ATX, 1 x 8pin ATX12V | |
| Other | 1 x POST, 1 x LPC, 1 x 4 PWM fan support | |
| Rear I/O | USB | 4 x 3.2 Gen2 |
| 2 x 3.2 Gen1 | ||
| Ethernet | 2 x 1GbE (i219LM/i211AT) | |
| Serial Ports | 2 | |
| Audio | 1 x microphone jack | |
| 1 x speaker out jack | ||
| 1 x line-in jack | ||
| Power | N/A | |
| Security | TPM2.0 | SLB9670 or PTT |
| Watchdog | Programmable | 1-255 seconds |
| Environmental | Operating Temp | 0~60°C (32~140°F) |
| Non Operating Temp | -40~75°C | |
| Operating Humidity | 0%~90% relative humidity, non-condensing | |
| Compliance | Certifications
| FCC, CE, RoHS |
| Ordering | Part Number | W48AX |
